WDX technology

In terms of water treatment based on biological principles, our patented vertical labyrinth technology is one of the top three solutions in the world. It combines 25 years of biological research with the latest cutting-edge Internet of Things (IoT) technologies.

WYDREX (WDX) technology is available in two versions, depending on the volume of water being treated. Both are suitable for water reclaim and wastewater treatment, as they deliver the same effluent quality results. The two versions are:

• Self-contained polypropylene treatment stations for medium-sized installations (50 to 2,400 population equivalent)
• Built concrete wastewater plants (for 2,000 to infinite population equivalent)

How it works

The treatment technology is based on a continually operated, modified activated sludge process. The biological reactor comprises an anaerobic chamber, aerated chamber, final clarification chamber and an integrated retention chamber. The chambers are connected by internal circulation and recirculation conduits between the compartments of the anaerobic chamber, between the anaerobic and final clarification chamber, and between the aerated chamber and final clarification chamber. The anaerobic chamber is divided by a series of overflowed and under-flowed baffles into compartments, creating the “Vertical Labyrinth”.

A flow control device is incorporated into the final clarification chamber, which enables the use of the volume of the integrated retention chamber in all the compartments and tanks of the wastewater treatment plant during peak flows and thus protects against the overloading of the plant.
